Mono 280W-335W

Mono 280W-335W

MORE POWER MORE RELIABLE
Module efficiency up to 21.2%
Compatible with mainstream trackers
Cost effective product for utility power plant.
Better shading tolerance.
Lower internal current,lower hot spot temperature Minimizes micro-crack impacts Heavy snow load up to 5400 Pa, wind load up to 2400 Pa.

PRODUCT DETAILS:

Nominal Max. Power (Pmax) 280W 290W 300W 320W 325W 330W 335W
Opt. Operating Voltage (Vmp) 32.3V 32.5V 32.7V 33.4V 33.6V 33.8V 34V
Opt. Operating Current (Imp) 8.67A 8.92A 9.17A 9.59A 9.68A 9.77A 9.87A
Open Circuit Voltage (Voc) 38.76V 39V 39.24V 40.9V 41.1V 41.3V 41.5V
Short Circuit Current (Isc) 9.36A 9.63A 9.9A 10.15A 10.2A 10.31A 10.36A
Module Efficiency 17.00% 18.00% 19% 19.18% 19.48% 19.78% 20.08%
Operating Temperature ~40°C ~ +85°C
Max. System Voltage 1500V (IEC) or 1000V (IEC)
Module Fire Performance CLASS C (IEC 61730)
Max. Series Fuse Rating  20 A
Application Classification Class A
Power Tolerance 0 ~ + 10 W
Cell Type 156.75mm wafer/Mono 158.75mm wafer/Mono
 Cell Arrangement 60 [10 X 6]
Dimensions 1640 X 992 X 35 mm 1665 X 1002 X 35 mm
 Weight 22.5 kg (49.6lbs)
Front Cover  3.2 mm tempered glass
 Frame Anodized aluminium alloy, crossbar enhanced
J-Box  IP68, 3 bypass diodes
Cable  4 mm2 (IEC)
Per Pallet  30 pieces
Per Container 40HQ/1000 pieces
